Key Features

Why SolarEdge Battery Bank battery?

Home batteries allow you to maximise the use of your solar power and minimise your energy bills by storing excess electricity produced during the day for use:

  • at night
  • on low sunlight days
  • when utility rates are more expensive
  • during blackouts.

Model BAT-10K1PS0B-01(1)
Output
Usable Energy (100% depth of discharge) 9700Wh
Continuous Output Power 5000W
Peak Output Power in Backup (for 10 seconds) 7500W
Peak Roundtrip Efficiency >94.5%
Voltage Range 350 - 450% Vdc
Additional Features
Compatible Inverters SolarEdge Genesis Single Phase Inverter, SolarEdge Energy Hub Single Phase Inverter
Batteries Per Inverter Up to 3(2)
Communication Interfaces Wireless and RS485*
Standard Compliance
Certification Cell - IEC 62619, UL1642
Battery - IEC 62619, UN38.3, UL1973, UL9540
Emissions IEC61000-6-1, IEC61000-6-2, IEC61000-6-3
Installation Specifications
Dimensions (W x H x D) 790mm x 1179mm x 250mm
Weight 121kg
Mounting Floor(3) or wall mount
Operating Temperature(4) -10°C to +50°C
Storage Temperature (more than 3 months) -10°C to +30°C
Storage Temperature (less than 3 months) -30°C to +60°C
Enclosure Protection IP55 - indoor and outdoor
Maximum Altitude 2000m
Cooling Natural convection
Noise at 1m Distance <25 dBA
Warranty
Solahart Warranty(5) 10 Years (Product Warranty) / 10 Years (Performance Warranty)







*The SolarEdge Energy Bank is designed for use with SolarEdge Energy Net for wireless communication. The inverter might require a matching SolarEdge Energy Net Plug-in.
†Products are optional extras. ^Design limitations apply. Please refer to your local Solahart Dealer.

(1)These specifications apply to part number BAT-10K1PS0B-01 (2)Installations with multiple SolarEdge Energy Bank batteries require a pair of branch connectors (DC + and DC -) per battery, excluding the last battery. The branch connectors should be purchased separately. (3)The floor stand is purchased separately. One floor stand is required per SolarEdge Energy Bank battery. (4)Please note that operating the SolarEdge Energy Bank at extreme temperatures for extended durations of time may void the Energy Bank’s warranty coverage. Please see the Energy Bank Limited Product Warranty for additional details. (5)For full details see Solahart Owner’s Guide. Conditions Apply.

SolarEdge battery

    1. The SolarEdge Energy Bank battery can black start when the Grid is down so long as the appropriate SolarEdge hybrid inverter is installed with the battery.
    2. SolarEdge battery requires a Gateway (Backup box) to function
    3. Battery Model : BAT-10K1PS0B   : Back Up Box: BI-NAUGN-01

Why SolarEdge Home Battery?

The SolarEdge Home battery has been designed with performance, safety and maximum energy efficiency in mind.

This world-class lithium-ion battery can recharge using electricity generated from your solar panels or the grid when utility rates are low. It then sends power to your home in the evening, when the sun is not shining, or when utility rates are higher. The battery also serves as a backup in the event of a blackout.

When the SolarEdge inverter and Home battery are used together, the inverter’s capacity can be increased by up to 300%^. This means you can add more panels to your PV system than a standard installation, which allows you to produce more energy at a very cost-effective price. Up to 3 batteries can operate in parallel per inverter.

As more products, like electric vehicles, become linked to home energy generation and storage devices, this extra capacity is an excellent way to future-proof your home.

How you benefit:

High Efficiency
Store more of your solar energy for self-consumption and reduce your energy costs.

Modular Design
Scalable battery module design allows you to choose the most appropriate system for your household and then expand your storage capacity as your needs change.

Safety and Reliability
Extensive life-testing of the lithium-ion battery chemistry ensures reliability, energy retention and superior safety levels.

Solahart Warranty
Enjoy a 10-year product warranty and a 10-year performance warranty for extra peace of mind.

SolarEdge Energy Bank Battery Downloads



Datasheets

SolarEdge Energy Bank Battery Brochure: Download
